Mechanics> To a gro7nd observer the block C is movin...

To a gro7nd observer the block C is moving with v(not) and the block A with v1 and B is moving with v2 relative to C as shown. Identify correct statement.
A. v1-v2=v0
B. v1=v2
C. v1+v0= v2
D. None

Janvi , 6 Years ago

Grade 12th pass

2 Answers

Saurav

to make it complex lets think of CONSTRAINT MOTION

now if you are scared enough just think of easier method

what strikes us now is LETS STOP C or in other word talk everything relative to C

now its sipmle two blocks A and B connected with a thread (which is inextensible) and by commonsense now velocity of block A relative to C will be equal to velocity of B relative to C

that is v1-v(knot)=v2

that is optionA

aprove if it helps you as it motivates me to answer more

Last Activity: 6 Years ago

Khimraj

Since in neither frame the string should break, the speed of blocks A and B along the string must be same in all frames.

Thus in the frame of block C, the speeds of blocks A and B along the string must be same.

Thus

v1 – v2 = v0

Last Activity: 6 Years ago
