Grade 12Mechanics
This question has more than one answers correct.. pls help
This question has more than one answers correct.. pls help
1 Answer
Arun
Approved Tutor Answer6 Years agoBoth rotational motion and translational motion indicates that point O will slide towards left, thus kinetic friction will act towards right.
f
k
=μMg=.08×(50×10)=40N
As T=200N>f
k
, thus a will also be towards left.
Ma=T−f
k
50a=200−40⟹a=3.2m/s
2
Also, about C: TR
1
−f
k
R
2
=MK
2
α
200(0.3)−40(0.6)=50(0.3)
2
α
⟹α=8rad/s
2
