Grade 12Mechanics

the position X time T graph for a particle of mass 1 kg moving along x-axis is shown in the figure find impulse on a particle at t is equal to 4 second

Question image for the position X time T graph for a particle of mass
Profile image of Mega thilagaa
8 Years agoGrade 12
Answers icon

1 Answer

Profile image of Arun
8 Years ago

Impulse = Pf - Pi         (where P = momentum = mv)
P= m*(d/t) = 1*(20/4) = 5 kg m/s
P= m*(d/t) = 1*(-20/4) = -5 kg m/s

I = Pf - Pi = -5 -5 = -10 kg m/s
