Grade 11Mechanics
sir please provide the answer as immediately......................................................................
sir please provide the answer as immediately......................................................................
1 Answer
Venkat
Approved Tutor Answer8 Years agoam1=1.2+x
am2=2-x
T-40x=448
T+60X=720
Solve for x,
x = 2.72
T = 400+40(1.2+2.72) = 556.8
a1=1.2+2.72 = 3.92
a2=2-2.72 = -0.72
arelative = 3.92—(-0.72) = 4.64
s=ut+0.5at2
5=4.64(0.5) t2
t = 1.466 s
I cannot upload the image file as there is no option to do the same...
