Mechanics> Please sir answer this question It is one...

Please sir answer this question It is one of the toughest and tricky question. Please sir answer this question.

Kaushki , 7 Years ago

Grade 12th pass

1 Answers

Piyush Kumar Maurya

So this question is to be dealt through non inertial frame of reference using the concept of pseudo force.

Draw fbd of block m2

The eqn would be - m2*a*cos beta = T + m2*g*sin beta ....(I)

Here m2*a*cos beta is the component of pseudo force that is acting at an angle beta opposite to initial direction of acceleration

Now draw fbd of block m1-

The eqn would be - T + m1*a*cos alpha = m1*g*sin alpha.... (II)

Here m1*a*cos alpha is the component of pseudo force acting at an angle alpha opposite to the direction of initial acceleration.

On combining both equations

a= m2*g*sin beta + m1*g*sin alpha / m1*cos alpha + m2* cos beta

Last Activity: 7 Years ago
