Grade 11Mechanics

Please send me the solution to the above question as soon as possible.

Question image for Please send me the solution to the above question

supraja venkatraman

7 Years agoGrade 11

1 Answer

Samyak Jain

7 Years ago

Potential energy of two masses m1 and m2 separated by distance r is – G m1.m2 / r.
In given problem m and 2m are separated by 2 $\l$ , m and 3m by $\l$ and 2m and 3m by $\sqrt{(2l)^{2} + (l)^{2}}$ = $\sqrt{5}l$ .

[It is a right angled triangle.]

Potential energy of the system is (– G(m)(2m)/2 $\l$ ) + (– G(m)(3m)/ $\l$ ) + (– G(2m)(3m)/ $\sqrt{5}l$ )

= – (Gm²/ $\l$ )[2/2 + 3 + 6/ $\sqrt{5}$ ]

= – (4 + 6 / $\sqrt{5}$ ) Gm²/ $\l$
