Flag Mechanics> please see the attatched image please see...
question mark

please see the attatched image
please see the attatched imageplease see the attatched imageplease see the attatched imageplease see the attatched imageplease see the attatched imageplease see the attatched imagev
give answer with reasons

kavishka , 6 Years ago
Grade 12
anser 1 Answers
Vikas TU
Draw the free boy diagram first.
2Nw = 2mg +Mg
Nw = mg + Mg /2
Fx = f
Nc Cos45 =μNw
MgCos45*Cos45 = μ(mg+Mg/2)
M/2 = μm + μM/2
M = 2μm + 2μM
M = 2μm/1-μ
hope this helps
