Flag Mechanics> please give the answer as ..................
question mark

please give the answer as ............................................... .

Anand Entertainment , 7 Years ago
Grade 11
anser 1 Answers
Venkat
Construct a Free body diagram by drawing a line perpendicular to the inclined plane to cut  the strings.Take the man and trolley as a FBD.
Tension in the upper pulley is 250 N
Tension in lower pulley is 250 x 2 = 500 N
The net  force up the incline is = 250 + 500 = 750 N
The net force down the incline = 100 x  9.81 x  sin(15°) = 255 N
Calculate the net upward force
F net = 750 - 255 = 495 N

Calculate the acceleration
a = Fnet/ mass = 495/100 = 4.95 m/s2
ApprovedApproved
