Grade 12th passMechanics

Neglecting friction everywhere,find the acceleration of mass M,assume m>m'......with solution, please help me solving such questions which have blocks connected to pulleys which are moving relative to another moving block.

Question image for Neglecting friction everywhere,find the accelerat
Profile image of Priyanshu sharma
6 Years agoGrade 12th pass
Answers icon

1 Answer

Profile image of Ayush_Deep
6 Years ago
Consider the two blocks m and m' moving in horizontal motion.
Their acceleration are g/2 but in opposite direction.
Since their is not external force the acceleration of center of mass will be zero.
Since the heavier mass m>m' moves in -ve x axis by g/2 acceleration the whole system will move towards +be x axis with an acceleration a.
No net force
m1a1+m2a2+m3a3+m4a4+..... = 0
-mg/2 + m'g/2 + (2m+2m'+M)*a=0
a= (m-m')g/2(2m+2m'+M)
Hope you got correct answer.
