Is the relationship ∆ϕ1 + ∆ϕ2 = ∆ϕ2 + ∆ϕ1 valid if ∆ϕ1 and ∆ϕ2 refer to different axes of rotation? Is it valid if they refer to different rotations about the same axis?

Profile image of Radhika Batra
11 Years agoGrade 11
Answers icon

1 Answer

Profile image of Kevin Nash
11 Years ago

It can be seen from the figure above that the book is rotated about the x axis twice by 20° . One can observe that the commutative law of addition remains validated when the axis of rotation is kept same.
