Grade 11Mechanics
A constant force of magnitude 2.6 N acts on the particle. Find the components of the torque about the origin when the force acts in (a) the positive x direction and (b) the negative z direction.
1 Answer
Aditi Chauhan
(a) When the force acts in the positive x direction, the vector force can be written in unit vector notation as:
Substitute the values in the expression of cross product given by equation (1),
(b) When the force acts in the negative z direction, the vector force can be written in unit vector notation as:
Substitute the values in the expression of cross product given by equation (1),
(b) When the force acts in the negative z direction, the vector force can be written in unit vector notation as:
