Grade 10Mechanics

A block is tied to the middle of a string and suspended from one end as shown in figure. Here M is the block and O is the point of suspension. If you give a sharp jerk at J, the string will break (a)below the point (b)from above the block (c)at the point J itself (d)none of these. Explain..... In the above question , if we increase the pull at J gradually , the string will break. (a)Below the block (b)from above the block (c)at point J itself (d)none of these

Question image for A block is tied to the middle of a string and susp
Profile image of Prakhar Raj
8 Years agoGrade 10
Answers icon

1 Answer

Profile image of Arun
8 Years ago
If the free end of the string is given a sufficiently sharp jerk the string is likely to break between hand and stone - leaving the stone suspended. The inertia of the stone`s mass will limit the strain imposed on the string above it - the stone has to accelerate in response to the impulse (F*t) applied .. this movement will be significantly less than the movement sustained by the string below (which has insignificant inertia).
