Magnetism> Two circular coils are made from a unifor...

question mark

Two circular coils are made from a uniform wire the ratio of radii of circular coils are 2:3 and no. of turns is 3:4. If they are connected in parallel across a battery. Find ratio of magnetic inductions at their centres.

Rohan veenu , 7 Years ago

Grade 12

1 Answers

Eshan

Dear student,

The magnetic field at the center of each coill is given by-

$B=\dfrac{\mu_0Ni}{2R}$
$\implies \dfrac{B_2}{B_1}=\dfrac{N_2}{N_1}\times \dfrac{I_2}{I_1}\times\dfrac{R_1}{R_2}$
Also the ratio of resistances will be $\dfrac{r_2}{r_1}=\dfrac{l_2}{l_1}=\dfrac{N_2(2\pi R_2)}{N_1(2\pi R_1)}$ ,
$\implies \dfrac{I_2}{I_1}=\dfrac{r_2}{r_1}=\dfrac{N_1R_1}{N_2R_2}$
Use these ratios to find the answer.

Last Activity: 7 Years ago
