Please explain the problem in image fully stepwise ......#....clearly........

Question image for Please explain the problem in image fully stepwis
Profile image of Sudhanva G V
7 Years agoGrade 11
Answers icon

1 Answer

Profile image of ADARSH SINGH
7 Years ago
in the question , the block below is experiencing two forces , one due to the friction and other due to the tension in that string . also the frictional froce acts in the direction of movement of both of them on block and opposite to that direction on the man . the tension
                                   T=100 N
                                 let n m/s-2 be the common accelaration of the man and the block below man .
                                AND LET f BE THE FRICTION (WHICH WOULD BE SAME ON BOTH OF THE BLOCK AND MAN .
                                now by f(net external) = ma

taking the block, we see ,
                                T-f = ma = 50n
and in the block , we see ,
                                T+f=ma=100n

adding both the equations above , we get ,
                                 2T=150n therefore, a=4/3 m/s-2         (since T=100N)

substituting this value of n in any of the equations , you can easily get ,
                                 f = 100/3N

hence , the requiered value of X in the question is 3
