ADNAN MUHAMMED

Grade 12,

Courses New

Please kindly see the attachment and solve question no 8 asap..... Thanks for the help πŸ˜„πŸ˜„πŸ˜„πŸ˜„πŸ˜„πŸ˜ƒπŸ˜ƒ

Please kindly see the attachment and solve question no 8 asap.....
Thanks for the help πŸ˜„πŸ˜„πŸ˜„πŸ˜„πŸ˜„πŸ˜ƒπŸ˜ƒ

Question Image
Grade:12th pass

1 Answers

Vikas TU
14149 Points
4 years ago
Given data: Two block of masses 7 kg and 35 kg respectively. Block with mass of 35 kg is resting on the friction less ground and block of mass 7 kg is resting upon it as shown in the figure in the question.
The coefficient of friction, Β΅s = 0.5
The coefficient of kinetic friction, Β΅k = 0.4
Force, F = 100 N is applied on block of mass 7 kg.
Let us say block of mass 7 kg as β€œBlock B” and block of mass 35 kg as β€œBlock A”.
Β
The limiting static frictional force on Block B, = Β΅s * mass of B * g
Β  Β  Β  Β  Β  Β = 0.5 * 7 * 9.8 ………..[ taking g = 9.8 m/sΒ² ]
Β  Β  Β  Β  Β  Β = 34.3 N
∴ 34.3 N
Hence, (limiting static frictional force on B)
∴ Since the static frictional force on B is less than the applied force of 100 N on it, so the block B will have some motion which will be then opposed by the kinetic friction acting upon it.
∴ force due to kinetic friction on B = ¡k * mass of B * g
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  = 0.4 * 7 * 9.8
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  Β  = 27.44 N
Now, due to the opposed kinetic friction on B, block A will experience some motion. Since the ground on which A is resting has no friction therefore, force acting on A will equal to the force due to kinetic friction on B I.e., equal to 27.44 N.
We know,
Β  F = m * a
Therefore,Β Β
Acceleration of block A = (force due to kinetic friction on B) / (mass of A)
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β = (Β΅k * mass of B * g) / 35
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β = 27.44 / 35
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β = 0.784 m/sΒ²
Β  Β  Β  Β  Β  Β  Β  Β  Β  Β β‰ˆ 0.8 m/sΒ²Β
