General Physics
I m not able to calculate the eq capacitance. Is there a way to solve this question easily
I m not able to calculate the eq capacitance. Is there a way to solve this question easily
1 Answer
Vikas TU
Dear student
The circuit is in wheatstone bridge ,
No no charge will flow through middle capacitance,
eq capacitance = ¾ + ¾ = 1.5 micro farad
Good Luck
