A long insulated copper wire is closely wound as a spiral of ‘N’ turns. The spiral has inner radius ‘a’ and outer radius ‘b’. The spiral lies in the XY plane and a steady current ‘I’ flows through the wire. The Z-component of the magnetic field at the centre of the spiral is ?

A long insulated copper wire is closely wound as a spiral of ‘N’ turns. The spiral has inner radius ‘a’ and outer radius ‘b’. The spiral lies in the XY plane and a steady current ‘I’ flows through the wire. The Z-component of the magnetic field at the centre of the spiral is ?

Grade:11

2 Answers

Saurabh Koranglekar
askIITians Faculty 10336 Points
2 years ago
Vikas TU
14149 Points
2 years ago
Dear student
Please refer the clear image ,
The image above does not looks good , it is blurr.
Hope for the best
Good Luck
Cheers
