Find the current through the three resistors for the circuit attached

Gudimetla Koteswara Rao , 7 Years ago
Grade 12th pass
anser 2 Answers
Arun
Dear student
Equivalent voltage of battery = 4 -2 = 2 volt
Now equivalent resistance = 4+6 = 10 ohm
4 ohm in upper arm will have no current as current will not pass through it because current will pass thriugh least resistance branch.
Now current = 2/10 = 0.2 amp in 4 ohm and 6 ohm
Last Activity: 7 Years ago
Khimraj
4ohm resistance has short circuit. so current through 4 ohm is zero.
net EMF = 4-2 = 2V
current through 4 and 6 ohm = 2/10 = 0.2A
Hope it clears.
