Find the current through the 10 ohm resistor from the fig attached

Question image for Find the current through the 10 ohm resistor from

Gudimetla Koteswara Rao

8 Years agoGrade 12th pass

2 Answers

Eshan

8 Years ago

Deat student,

Apply Kirchoff’s law to the two loops to eliminate the two unknown variables $i_1$ and $i_2$ .

Hence, $4.5=3(i_1+i_2)+6i_2=3i_1+9i_2 \implies 1.5=i_1+3i_2$

For the smaller loop, $3+10i_1=6i_2$

Hence $i_1=0,i_2=0.5A$

Kushagra Madhukar

5 Years ago

= 0.5 A₂ = 0; i₁Hence, i $3+10i_1=6i_2$ For the smaller loop, $4.5=3(i_1+i_2)+6i_2=3i_1+9i_2 \implies 1.5=i_1+3i_2$ .Hence, $i_2$ and $i_1$ Deat student,Please find the solution to your problem below.Apply Kirchoff’s law to the two loops to eliminate the two unknown variables

Hope it helps.

Thanks and regards,

Kushagra
