A Pentagon wire mesh is formed with the help of ten resistance wire, each of resistance R as shown in fig. Find the equivalent resistance across ED

A Pentagon wire mesh is formed with the help of ten resistance wire, each of resistance R as shown in fig. Find the equivalent resistance across ED

Question Image
Grade:11

1 Answers

Pooja
127 Points
4 years ago
We have to find equivalent resistance across ED



We have to find equivalent across ED

So let E be at potential V and D at 0
Now there is potential drop across each resistor and the resulting potential be V1
So potential at points A,B and C will be V1
When two points are at same potential no current will pass so resistors AB,BC and AC
Can be eliminated
Now in the remaining circuit the resistors AE, BE and CE will have same potential difference they are parallel
R1=R/3
Same way AD,CD and BD are parallel
R2=R/3

Now R2 and R2 are  in series
R3 =R1+R2=2R/3
Now R3  is in parallel with ED
So equivalent resistance would be
Req=(2R/3 ×R) ÷(2R/3 + R)

{P.S. try removing resistors you will get it as I cannot upload figure or draw it}
      =2R/5
