For the circuit shown in figure minimum current will flow through and maximum current will flow through

For the circuit shown in figure minimum current will flow through and maximum current will flow through

Question Image
Grade:12th pass

1 Answers

Vikas TU
14149 Points
6 years ago
Dear Student,

Let the current supplied by the battery is i.
current passing through 2W = ixopposite resistance/total resistance in the parallel loop
=ix2/3 =0.67i
Current through 4W= ixopposite resistance/total resistance in the parallel loop
=ix1/3
=0.33i
current through 3W= ixopposite resistance/total resistance in the parallel loop
=ix5/8=0.62i
current through 5W= ixopposite resistance/total resistance in the parallel loop
=ix3/8=0.36i
Maximum current through = 2W
Minimum current through=4W
where W = ohm.
Cheers!!

Regards,
Vikas (B. Tech. 4th year
Thapar University)
